Gas Standard Station Compressor

Qingdao Lenado Intelligent Equipment Co., Ltd. is one of the most reliable manufacturers and suppliers of gas standard station compressor in China. With a professional production team, we are able to meet the needs of the majority of our customers. Welcome to wholesale bulk customized gas standard station compressor from our factory.

Natural Gas Standard Station Compressors - Providing Reliable Natural Gas Compression Solutions for Refueling Stations

Oil-Free, Hydraulically Driven, Skid-Mounted Design - Specifically Engineered to Boost Pipelined Natural Gas to 23 MPa (Up to 25 MPa)

As natural gas gains increasing favor as a clean and economical transportation fuel, the Natural Gas Standard Station Compressor has emerged as a critical link between urban gas pipeline networks and CNG-powered vehicles. Whether referred to as a "Natural Gas Standard Station Compressor" or a "CNG Standard Station Compressor," the core technological principles remain identical: both are designed to safely and efficiently boost low-pressure natural gas to the high-pressure levels required for vehicle refueling.

Genketech Gas offers a comprehensive range of Natural Gas Standard Station Compressors, custom-tailored to accommodate inlet pressures ranging from 0.8 MPa to 4.0 MPa (and higher), with discharge pressures reaching up to 25 MPa. Featuring a 100% oil-free design and hydraulic drive technology, our equipment is specifically engineered for continuous-duty operation at urban and suburban natural gas refueling stations.

1. Oil-Free Compression - Ensuring Natural Gas Purity

- Lubricating oil does not enter the compressor cylinder → Completely eliminates the risk of oil contamination.

- Effectively protects downstream equipment (such as dryers, refueling dispenser valves, and vehicle engine injectors).

- Eliminates the need for expensive oil-removal filters and the frequent disposal of waste oil.

2. Hydraulically Driven Pistons - Smooth Operation and Exceptional Durability

- The hydraulic drive system effectively absorbs shock loads, thereby significantly reducing wear on moving components.

- Generates lower noise and vibration levels compared to traditional crankshaft-and-connecting-rod compressors.

- Equipped with a standard soft-start function - completely eliminating the high transient inrush currents typically generated during startup.

3. Wide-Range Inlet Pressure Adaptability

- Standard models are perfectly suited for pipeline pressures ranging from 0.8 to 4.0 MPa.

- For lower inlet pressures (down to a minimum of 0.2 MPa), we offer customized four-stage compression solutions.

- For high-inlet-pressure conditions (up to 10 MPa), we offer single-stage booster solutions as an option.

4. Intelligent Control and Remote Monitoring

- PLC + Color Touchscreen - Real-time display of suction pressure, discharge pressure, and temperature data.

- Soft Starter - Enables smooth, gradual motor startup.

- Optional GSM/4G Module - Facilitates remote alarm notifications and data logging capabilities.

5. Low-Noise Design - Ideal for Urban Gas Refueling Stations

- Sound-Insulating Enclosure Design - Reduces noise levels to ≤ 85 dB(A) at a distance of 1 meter.

- Water-Cooled Air Cooling System - Features a compact footprint suitable for outdoor installation (the radiator unit can be positioned independently).
